Dr. Super-Evil Hydro 2

279,00 EUR
19 % VAT incl. excl. Shipping costs
Shipping time: 3-6 business days
Product no.: 22834
Stock:
Manufacturer: Hydro&Marine O. Siess
More products of: Hydro&Marine O. Siess


Products description

Dr. Super Evil WE
4-Point-Competiton Outrigger

Newly developed high-performance Outrigger for 4- (6) LiPo or Class II Hydro

Prototype:
Dr. Super Evil has been derived from our success Outrigger Mr. Krabs and was specifically designed for the competition class
Hydro II.

Model:
Completely new sponon construction with improved cornering stability, extra-wide body for LiPos, also suitable for speed tuning.
Super-Evil was developed hot hydro II high performance, but can also be used for fun and extreme-Speed driver in the field
4-6 LiPos. ( 2x2 or 2x3 till 5000 mAh)


Hull include:

  •     Hull finished in epoxy, fiberglascarbon&cevlar
  •     Glossy white colored
  •     Reinforced hull bottom and float bottoms in carbon&cevlar
  •     2 mm fiberglas black Sponson holders
  •     2 x Carbon Tubes
  •     CD building instructions


Technical Specifications:
Length                     :    890 mm
Length (overall) *     :    990 mm *
Width                       :    550 mm
RC                           :    Speed Control, Rudder
Number of cells       :    4-6 LiPos
Drive E-version       :    Lehner 1950 or  Leopard 3674, 4050-4082
Competition class   :     Hydro II

* LOA defines the overall dimensions of the model with rudder.

More images can be found in our photo archive (click here) frown


Motor Setup Leopard Sport  (inexpensive China-Motor) :
4s1p  =  Leopard LBP3674B/2.5D Brushless Motor 4polig -2650kV-   (Zellen bis ca. 3200 mAh - Lightweight Setup)
4-5s1p  =  Leopard LBP4074B1/5Y Brushlesse Motor 4polig 2650kV-  (Zellen bis ca. 5000 mAh)

Motor Setup LEHNER High-Speed  (Quality  German made Motor) :


Motor Setup LEHNER Dragster-Speed  (Quality  German made Motor) :
4s1p*- 5 Windungen   = Lehner 2240 HiAmp Air&Watercooled (Zellen bis ca. 5000 mAh)
6s1p*- 7 Windungen   = Lehner 2240 HiAmp Air&Watercooled (Zellen bis ca. 4000 mAh (Dragster Setup - for experts only)
